Secure CI/CD from GitHub Actions to a VPS: Docker, GHCR, nginx, and the Traps

This is the pipeline I wish I had written down before the first production deploy: GitHub Actions runs tests, builds a Docker image, pushes it to GitHub Container Registry, SSHs into a VPS, and rolls the stack with Compose. The VPS already serves other sites on ports 80 and 443, so the new API cannot steal those ports.

The sample app is Harbor, a fictional Django REST API that powers a public product catalog. Postgres, Redis, Celery, Gunicorn, and nginx. Nothing about its business rules matters. The same shape works for any API you do not want sitting on the public internet as a raw :8000.

What you are assembling

flowchart TD
  accTitle: Harbor CI/CD and request routing
  accDescr: GitHub Actions tests the code, builds and pushes an image to GHCR, then deploys over SSH. The VPS pulls images, runs the release step, starts services, and checks application health. Host nginx routes public HTTPS requests to loopback-only services.

  developer["Developer: git push"] --> tests["GitHub Actions: pytest"]
  tests --> build["Build and push Docker image"]
  build -->|Store image tagged by git SHA| registry["GitHub Container Registry"]
  build -->|After successful push| deploy["GitHub Actions: SSH deploy"]
  deploy --> script

  subgraph vps["VPS"]
    script["scripts/deploy.sh"] --> pull["Docker Compose: pull images"]
    pull --> dependencies["Start Postgres and Redis"]
    dependencies --> release["Run release step"]
    release --> services["Start application services"]
    services --> health["Wait for application health check"]

    services -.->|Manages| nginx["Compose nginx: 127.0.0.1:18080"]
    services -.->|Manages| api["Gunicorn: 127.0.0.1:18100"]
    services -.->|Manages| celery["Celery worker and beat"]

    host["Host nginx: TLS on ports 80/443"]
    host -->|/static/ and /media/| nginx
    host -->|API and admin requests| api
  end

  registry -->|Image download| pull
  browser["Browser: HTTPS to api.harbor.example"] --> host

Three ideas keep this from turning into "Docker published 80 and broke WordPress":

1. CI never deploys a failing test suite. Deploy is a second workflow (or a later job) that needs: test.
2. The VPS pulls images. It does not build them. Builds happen on GitHub runners, tagged by git SHA, stored on GHCR.
3. Host nginx owns the public ports. Compose binds Gunicorn and an inner nginx to loopback only (127.0.0.1), so nothing extra is reachable from the internet.

Repo layout that survives production

Keep a dev Compose file that builds locally, and a prod Compose file that only references registry images:

GitHub Actions: split CI from deploy

CI on every PR

Keep CI dumb and fast. For Django, the runner often has no Postgres: use the project's test settings (SQLite, eager Celery) so pytest does not need the prod stack.

# .github/workflows/ci.yml
name: CI

on:
  push:
    branches: [main, master]
  pull_request:

concurrency:
  group: ci-${{ github.workflow }}-${{ github.ref }}
  cancel-in-progress: true

jobs:
  test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-python@v5
        with:
          python-version: "3.12"
          cache: pip
          cache-dependency-path: requirements-dev.txt
      - run: pip install -r requirements-dev.txt
      - name: Provide Django env
        run: cp .env.example .env
      - run: pytest

Deploy only from the default branch

# .github/workflows/deploy.yml
name: Deploy

on:
  push:
    branches: [master]
  workflow_dispatch:

concurrency:
  group: deploy-production
  cancel-in-progress: false   # never abort a live rollout mid-migrate

permissions:
  contents: read
  packages: write             # GITHUB_TOKEN can push to GHCR

env:
  REGISTRY: ghcr.io
  IMAGE_NAME: ${{ github.repository }}

Then three jobs in order: test → build-and-push → deploy.

Push to GHCR

GitHub Container Registry wants a lowercase image name. github.repository can include capitals; Docker will reject the tag.

- name: Set image name (lowercase)
  run: echo "IMAGE=${REGISTRY}/${IMAGE_NAME,,}" >> "$GITHUB_ENV"

- uses: docker/login-action@v3
  with:
    registry: ${{ env.REGISTRY }}
    username: ${{ github.actor }}
    password: ${{ secrets.GITHUB_TOKEN }}

- uses: docker/build-push-action@v6
  with:
    context: .
    file: Dockerfile
    push: true
    tags: |
      ${{ env.IMAGE }}:${{ github.sha }}
      ${{ env.IMAGE }}:latest

Tag both the SHA (what you actually run) and latest (what humans type when debugging). Deploy should set IMAGE_TAG to the SHA, not latest, so a rollback is "previous SHA" instead of a race on the moving tag.

Secrets: what belongs where

Known hosts: generate them on the VPS

ssh-keyscan from Windows OpenSSH has bitten me: the host key format did not match what the Linux runner expected, and the job either failed StrictHostKeyChecking or silently disabled it.

On the VPS (or any Linux box that can reach it):

ssh-keyscan -p 22 YOUR.VPS.IP

Paste the full lines into the VPS_KNOWN_HOSTS secret. In the workflow:

- name: Configure SSH
  run: |
    mkdir -p ~/.ssh
    printf '%s\n' "${{ secrets.VPS_SSH_KEY }}" > ~/.ssh/deploy_key
    chmod 600 ~/.ssh/deploy_key
    printf '%s\n' "${{ secrets.VPS_KNOWN_HOSTS }}" >> ~/.ssh/known_hosts
    chmod 644 ~/.ssh/known_hosts

Use StrictHostKeyChecking=yes. Turning it off "just for CI" is how you accept a poisoned DNS record.

GHCR pull permissions (private images)

The pattern that avoids storing a long-lived PAT on the disk:

# inside the SSH script, using the job token
echo "$GITHUB_TOKEN" | docker login ghcr.io -u "$GH_ACTOR" --password-stdin

GITHUB_TOKEN expires when the job ends. The VPS does not keep a human PAT in ~/.docker/config.json from a chat message.

The SSH deploy step

Keep the YAML thin. The VPS script does the Compose work.

- name: Deploy over SSH
  env:
    VPS_HOST: ${{ secrets.VPS_HOST }}
    VPS_USER: ${{ secrets.VPS_USER }}
    VPS_PORT: ${{ secrets.VPS_PORT }}
    GIT_SHA: ${{ github.sha }}
    GHCR_IMAGE: ${{ env.IMAGE }}
    GITHUB_TOKEN: ${{ github.token }}
    GH_REPO: ${{ github.repository }}
    GH_ACTOR: ${{ github.actor }}
  run: |
    port="${VPS_PORT:-22}"
    ssh -i ~/.ssh/deploy_key -o StrictHostKeyChecking=yes -p "$port" \
      "${VPS_USER}@${VPS_HOST}" \
      "set -euo pipefail
       cd /srv/apps/harbor-api
       git -c credential.helper= fetch \
         'https://x-access-token:${GITHUB_TOKEN}@github.com/${GH_REPO}.git' \
         master
       git reset --hard FETCH_HEAD
       echo '${GITHUB_TOKEN}' | docker login ghcr.io -u '${GH_ACTOR}' --password-stdin
       export IMAGE='${GHCR_IMAGE}'
       export IMAGE_TAG='${GIT_SHA}'
       ./scripts/deploy.sh"

deploy.sh should:

1. Refuse to run without .env.prod
2. Export IMAGE / IMAGE_TAG (Compose does not read those from env_file)
3. Pull images
4. Run a one-shot release container: migrate + collectstatic
5. up -d the long-running services
6. Wait until web is healthy, then prune dangling images

Docker Compose: the landmines

env_file vs interpolation

This is the bug that ate the most hours.

• env_file: .env.prod injects variables into the container. Values are passed through. A $ in SECRET_KEY stays a $.
• ${DB_PASS} in the Compose YAML is interpolated by Compose before the container starts, using the shell and a .env file in the project directory. $uz8k inside a secret becomes "variable uz8k is not set".

# BAD — Compose eats $ inside the password
environment:
  POSTGRES_PASSWORD: ${DB_PASS}

# GOOD — Postgres reads POSTGRES_PASSWORD from env_file as a literal
env_file:
  - .env.prod
environment:
  POSTGRES_DB: ${DB_NAME:-harbor}
  POSTGRES_USER: ${DB_USER:-harbor}
  # password is NOT listed here

Put both DB_PASS and POSTGRES_PASSWORD in .env.prod, identical character-for-character (including $). Postgres only honors POSTGRES_PASSWORD on first volume init. If you booted the volume with a stripped password, you will fight auth errors until you dump that volume (and lose data) or change the role inside Postgres.

IMAGE is not in the container env_file

x-app-image: &app_image ${IMAGE}:${IMAGE_TAG}

That substitution happens on the host when you run docker compose. If you SSH in and type docker compose -f docker-compose.prod.yml up -d web with no exports, you get:

WARN The "IMAGE" variable is not set. Defaulting to a blank string.
unable to get image ':': invalid reference format

Always:

export IMAGE="$(grep -E '^IMAGE=' .env.prod | tail -1 | cut -d= -f2-)"
export IMAGE_TAG="$(grep -E '^IMAGE_TAG=' .env.prod | tail -1 | cut -d= -f2-)"
docker compose -f docker-compose.prod.yml up -d --force-recreate --no-deps web celery_worker

Do not bind 80/443 in Compose

On a VPS whose host nginx already terminates TLS for other vhosts, Compose nginx should be:

nginx:
  image: nginx:alpine
  ports:
    - "127.0.0.1:18080:80"

Gunicorn:

web:
  ports:
    - "127.0.0.1:18100:8000"

Pick loopback ports that are free. 18000 is a popular default and is often already taken.

One-shot migrate container

Do not let web, celery_worker, and celery_beat each run migrate on startup. Race. Run a release service with restart: "no" that migrate + collectstatic, and depends_on: release: condition: service_completed_successfully on the workers.

Healthchecks behind Django security settings

Production Django often has ALLOWED_HOSTS = ["api.harbor.example"] and SECURE_SSL_REDIRECT = True. A healthcheck of http://localhost:8000/ then returns 400 (wrong Host) or 301 (HTTP→HTTPS). Compose marks the container unhealthy forever.

Send the headers the real proxy sends:

healthcheck:
  test:
    [
      "CMD-SHELL",
      "python -c \"import http.client,sys; c=http.client.HTTPConnection('127.0.0.1',8000,timeout=4); c.request('GET','/admin/login/',headers={'Host':'api.harbor.example','X-Forwarded-Proto':'https'}); r=c.getresponse(); sys.exit(0 if r.status==200 else 1)\"",
    ]

TLS, two nginx hops, and the redirect loop

The failure mode: browser shows ERR_TOO_MANY_REDIRECTS.

Cause: two proxies both "helpfully" set X-Forwarded-Proto.

• Host nginx (TLS) should set X-Forwarded-Proto $scheme once.
• If you also set X-Forwarded-Proto $http_x_forwarded_proto and the incoming header is empty, Django sees HTTP and 301s to HTTPS, forever.

Worse: if host nginx proxies everything to compose nginx, and compose nginx proxies to Gunicorn, Django still sees a hop. SECURE_SSL_REDIRECT plus a missing proto header is a loop.

The split that stayed stable:

location /static/ {
    proxy_pass http://127.0.0.1:18080;
    proxy_set_header Host $host;
}

location / {
    proxy_pass http://127.0.0.1:18100;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header CF-Connecting-IP $http_cf_connecting_ip;
    proxy_set_header X-Forwarded-Proto $scheme;
}

Django:

SECURE_PROXY_SSL_HEADER = ("HTTP_X_FORWARDED_PROTO", "https")

Static files 404 next to a working admin HTML page

If STATIC_URL is the relative string static/ instead of /static/, the browser requests /admin/static/.... Gunicorn then serves HTML 404s. Fix STATIC_URL = "/static/", collectstatic into the volume compose nginx serves, and point /static/ at 18080, not Gunicorn.

Cloudflare in front of origin

1. DNS only (grey cloud) while you run certbot against the VPS. Orange-cloud will hide the origin and certbot HTTP-01 will fail unless you use DNS-01.
2. After the cert exists, you can orange-cloud. SSL mode must be Full (strict) — "Flexible" makes Cloudflare speak HTTPS to the visitor and HTTP to origin, which with SECURE_SSL_REDIRECT is another redirect loop.

Client IPs: why audit logs show 172.22.0.1

Gunicorn's REMOTE_ADDR is the last TCP hop. That is the Docker bridge or 127.0.0.1, not the visitor.

If you log request.META["REMOTE_ADDR"], every sign-in looks internal. Read, in order:

1. CF-Connecting-IP (only trustworthy when Cloudflare actually sits in front)
2. X-Real-IP if it is not RFC1918
3. The first non-private address in X-Forwarded-For
4. REMOTE_ADDR as fallback

And do not let compose nginx overwrite X-Real-IP with $remote_addr (the bridge). Pass $http_x_real_ip through.

Python's ipaddress.IPv4Address.is_private is broader than RFC1918 — documentation ranges like 203.0.113.0/24 count as private. If you skip "private" blindly, tests and some CGNAT clients look like the bridge again.

Outbound email

SMTP can be "working" and still refuse every message:

SMTPDataError: (550, b'The example.com domain is not verified.')

Resend (and most providers) verify a specific domain or subdomain. Verifying mail.example.com does not authorize no-reply@example.com. Set DEFAULT_FROM_EMAIL to an address on the verified name, recreate the workers, retry. Failed Celery tasks do not magically resend.

Password-reset mail in Django is often sent by Gunicorn during the request. Application / notification mail may go through Celery. Check docker compose logs web and celery_worker. The API returning 200 on "forgot password" does not mean an email exists — unknown addresses are silent by design.

GitHub / Docker security checklist

• Repository is private if the image or compose files leak internal hosts.
• permissions: on the deploy workflow is least privilege (contents: read, packages: write). Do not use contents: write unless you tag releases.
• GITHUB_TOKEN is not granted id-token or actions: write "just in case."
• .dockerignore excludes .env, .env.prod, *.pem, id_rsa, .git.
• Dockerfile is multi-stage, runs as a non-root app user, and does not leave compilers in the runtime image.
• Dependabot or a scheduled trivy scan on ghcr.io/you/harbor-api:latest.
• Branch protection: deploy workflow cannot be skipped by pushing --no-verify to a laptop; require the CI job on PRs.
• No pull_request_target with checkout of untrusted code and secrets. That combo is a classic injection.
• Actions pinned by SHA if you want supply-chain extra credit; at least stay on current major tags and watch github.blog advisories.

A field guide to errors you will actually see

Minimal deploy.sh shape

#!/usr/bin/env bash
set -euo pipefail
cd "$(dirname "$0")/.."

[[ -f .env.prod ]] || { echo "Missing .env.prod"; exit 1; }

IMAGE="${IMAGE:-ghcr.io/you/harbor-api}"
IMAGE_TAG="${IMAGE_TAG:-latest}"
export IMAGE IMAGE_TAG

while IFS='=' read -r key value; do
  case "$key" in
    DB_NAME|DB_USER)
      printf -v "$key" '%s' "$value"
      export "$key"
      ;;
  esac
done < <(grep -E '^(DB_NAME|DB_USER)=' .env.prod)

COMPOSE=(docker compose -f docker-compose.prod.yml)

"${COMPOSE[@]}" pull release web celery_worker celery_beat
"${COMPOSE[@]}" up -d db redis
"${COMPOSE[@]}" rm -sf release 2>/dev/null || true
"${COMPOSE[@]}" up --abort-on-container-exit --exit-code-from release release
"${COMPOSE[@]}" up -d --remove-orphans

deadline=$((SECONDS + 180))
web_id="$("${COMPOSE[@]}" ps -q web)"
while (( SECONDS < deadline )); do
  status="$(docker inspect --format='{{.State.Health.Status}}' "$web_id" 2>/dev/null || echo starting)"
  if [[ "$status" == "healthy" ]]; then
    docker image prune -f
    exit 0
  fi
  sleep 3
done
echo "web was not healthy in time" >&2
"${COMPOSE[@]}" ps
exit 1

What I would do on a greenfield VPS tomorrow

1. Create a sudo user, SSH keys only, disable password auth (I wrote about the baseline in Important Configurations When You Launch Your Cloud Server).
2. Install Docker Engine + Compose plugin. Do not install a second nginx in Compose on 80/443 if host nginx already exists.
3. Add a vhost, certbot on grey-cloud DNS, then optionally orange-cloud with Full (strict).
4. Copy .env.prod.example → .env.prod, generate secrets on the box, chmod 600.
5. Put GitHub secrets in (host, user, port, deploy key, known_hosts).
6. Push to master, watch test → GHCR → SSH, then curl -I https://api.harbor.example/admin/login/.
7. Only then point the frontend NEXT_PUBLIC_API_URL at that origin.

The pipeline is boring when it works: a SHA in GHCR, a loopback port, one TLS terminator, secrets that never crossed a chat window. The un-boring part is always the same list: $ in Compose, the wrong X-Forwarded-Proto, a PAT that cannot pull packages, and a healthcheck that probes localhost without a Host header.

If you steal one habit from this post, steal this: treat the VPS as a pull agent, not a build server, and treat GitHub as a builder, not a place to store database passwords.
